Level Switch

• Automation Grade
• Automatic

• Circuit Type
• SPDT

• Color
• Yellow and Blue

• Contact Resistance
• 50 m

• Current Rating
• 16A

• Finish Type
• Molded Plastic

• Insulation Resistance
• 100 M

• Material
• Polypropylene (PP)

• Max. Current
• 16A

• Max. Voltage
• 250V AC

• Mechanical Life
• 100,000 operations

• Mounting Type
• Cable Suspended

• No Of Poles
• 1

• Number of Module
• Single

• Operating Temperature
• -10C to 60C

• Product Type
• Float Level Switch

• Protection Level
• IP68

• Rated Voltage
• 250V AC

• Size
• Float size approx. 105 x 80 x 50 mm

• Temperature Range
• -10C to 60C

• Weight
• About 250g

• Application
• Liquid Level Measurement

• Connectivity Type
• Mechanical

• Display
• Direct Sight

• Features
• Automatic Level Indication, Durable, Easy Installation, Cost Effective, High Reliability, Maintenance Free

• Installation Type
• Side/Top Mounted

• Measuring Range
• As per requirement

• Mounting Type
• Flanged/Threaded

• Operating Temperature
• Upto 100C

• Output
• Level Indication

• Pressure Type
• Up to 10 Kg/cm2

• Product Type
• Tubular Level Indicator

• Sensor Type
• Tubular

• Usage & Applications
• Industrial liquid level measurement

• Working Temperature
• Upto 100C

• Accuracy
• 0.5% F.S.

• Application
• Water Treatment, Industrial, Environmental Monitoring

• Cable Length
• Customizable (Long Cable Option)

• Features
• Rugged Design, Corrosion Resistant, Long-Term Stability, High Accuracy

• Function
• Continuous Liquid Level Measurement

• Housing Material
• Stainless Steel

• IP Rating
• IP68

• Ingress Protection
• IP68

• Input
• 24V DC (typical)

• Interface
• RS485, 4-20mA Output

• Material
• Stainless Steel Body

• Measurement Range
• Customizable (up to several metres)

• Mounting Type
• Submersible

• Operating Temperature
• -20C to +80C

• Output
• 4-20mA / RS485

• Power Consumption
• Low Power

• Product Type
• Hydrostatic Submersible Level Transmitter

• Resolution
• High

• Response Time
• Fast

• Sensitivity
• High Sensitivity

• Sensor Type
• Hydrostatic Pressure Sensor

• Signal Type
• Other, Analog (4-20mA), Digital (RS485)

• Usage
• Water & Liquid Level Monitoring

• Voltage
• 24V DC

• Wireless
• No

• Automation Grade
• Automatic

• Circuit Type
• SPST/ SPDT

• Color
• Silver (Stainless Steel Finish)

• Contact Resistance
• Less than 100 m

• Current Rating
• 10 Amp

• Finish Type
• Polished Stainless Steel

• Insulation Resistance
• More than 100 M at 500 V DC

• Material
• Stainless Steel

• Max. Current
• 10 A

• Max. Voltage
• 230 V AC

• Mechanical Life
• Over 1 million operations

• Mounting Type
• Top Mounted

• No Of Poles
• Single Pole

• Number of Module
• Single

• Operating Temperature
• -10C to 70C

• Product Type
• Magnetic Level Switch

• Protection Level
• IP65

• Rated Voltage
• 230 V AC, 24 V DC

• Response Time
• Instantaneous (as per magnetic operation)

• Size
• Customizable as per requirement

• Stoke
• ---

• Temperature Range
• Up to 70C

• Weight
• Depends on model (Refer to datasheet)

• Accuracy
• 10 mm

• Application
• Chemical, Water, Oil, Process Industries

• Cable Length
• Up to 6 meters (as per requirement)

• Features
• Maintenance Free, Reliable Operation, Suitable for Hazardous Areas

• Function
• Continuous Level Monitoring

• Housing Material
• SS 304 / SS 316

• IP Rating
• IP68

• Ingress Protection
• IP68

• Input
• 24 V DC

• Interface
• 2 Wire Loop Powered

• Material
• Stainless Steel

• Measurement Range
• 300 mm to 6000 mm

• Mounting Thread
• 112 BSP(M)

• Mounting Type
• Threaded

• Operating Temperature
• -20C to +80C

• Output
• 4-20 mA DC

• Power Consumption
• Low Power

• Product Type
• Magnetic Level Transmitter

• Resolution
• Up to 10 mm

• Response Time
• Fast

• Sensitivity
• High

• Sensor Type
• Magnetic Float/Wire

• Signal Type
• Analog

• Usage
• Liquid Level Measurement

• Voltage
• 24 V DC

• Wireless
• No

• Automation Grade
• Automatic

• Circuit Type
• SPST/SPDT

• Color
• Metallic Silver

• Contact Resistance
• 100 m max

• Current Rating
• 5A @ 250 V AC

• Finish Type
• Polished/Brushed

• Insulation Resistance
• 100 M at 500 V DC

• Material
• Stainless Steel (SS304/SS316)

• Max. Current
• 5A

• Max. Voltage
• 250 V AC

• Mechanical Life
• 1 Million Operations

• Mounting Type
• Side Mounted

• No Of Poles
• Single/Double (Optional)

• Number of Module
• 1

• Operating Temperature
• -20C to +80C

• Product Type
• Side Mounted Level Switch

• Protection Level
• IP65

• Rated Voltage
• 250 V AC/DC

• Response Time
• Instantaneous

• Size
• Custom/As Required

• Temperature Range
• -20C to +80C

• Accuracy
• 0.1% of span

• Application
• Temperature Sensing and Process Automation

• Cable Length
• Optional, as per order

• Features
• Easy installation, High accuracy, Industrial Grade, Robust Build, Fast Response, Maintenance Free, Universal Compatibility

• Function
• Temperature Measurement & Signal Conversion

• Housing Material
• Aluminium Die Cast

• IP Rating
• IP65

• Ingress Protection
• IP65

• Input
• RTD PT100

• Interface
• 2-Wire Loop

• Material
• SS 304/SS 316 (Sensor Stem)

• Measurement Range
• -50C to +250C (Standard), can be customized

• Mounting Thread
• 12 BSP (Standard)

• Mounting Type
• Head Mounted

• Operating Temperature
• -20C to +60C (Transmitter Head)

• Output
• 4-20 mA

• Product Type
• Temperature Sensor with Head Mount Transmitter

• Resolution
• 0.1C

• Response Time
• <1 second (typical)

• Sensitivity
• High Sensitivity

• Sensor Type
• RTD PT100, Class A/B

• Signal Type
• Other, Analog Current Loop

• Usage
• Industrial Process, Pharmaceutical, Chemical, Food & Beverage etc.

• Voltage
• Loop Powered 24V DC

• Wireless
• No

• Automation Grade
• Automatic

• Circuit Type
• SPDT, DPDT

• Color
• Metallic Silver

• Contact Resistance
• 80 m max.

• Current Rating
• 10A

• Finish Type
• Stainless Steel Finish

• Insulation Resistance
• 100 M at 500V DC

• Material
• Stainless Steel

• Max. Current
• 10A

• Max. Voltage
• 250V AC

• Mechanical Life
• 1 million operations

• Mounting Type
• Side Mounted

• No Of Poles
• Single Pole (SPDT) / Double Pole (DPDT)

• Number of Module
• Single

• Operating Temperature
• Up to 150C

• Product Type
• Side Mounted Magnetic Level Switch

• Protection Level
• IP68

• Rated Voltage
• 250V AC

• Response Time
• <1 sec.

• Size
• Customizable / Standard options

• Temperature Range
• -10C to +150C

• Weight
• Varies with model / approx. 0.7 kg

• Accuracy
• 1% RH, 0.2C (typical)

• Application
• Industrial, Laboratory, Greenhouse, Cold Chain, Server Room, Clean Room, Building Automation

• Cable Length
• 1m/2m/3m (customizable)

• Features
• Digital Display, Alarm, Programmable Set Points, Long Life, Anti-Condensation, Easy Calibration

• Function
• Monitors, Displays, and Transmits Temperature & Humidity Data

• Housing Material
• ABS Plastic / Metal (as per model)

• IP Rating
• IP65/IP67 (as per model)

• Ingress Protection
• IP65 / IP67 (model specific)

• Input
• Ambient Temperature & Relative Humidity

• Interface
• RS485, Modbus, Analog Out, Relay

• Material
• High-grade Electronic Components and Enclosure Material

• Measurement Range
• Temperature: -40C to +125C; Humidity: 0% to 100% RH

• Mounting Thread
• Standard Industrial Thread (size varies by model)

• Mounting Type
• Wall, Duct, or Panel Mount (model specific)

• Operating Temperature
• -40C to +85C (operational range)

• Output
• Analog (4-20mA, 0-10V), Digital (RS485/Modbus, Relay)

• Power Consumption
• <2W

• Product Type
• Temperature & Humidity Sensor Controller & Transmitter

• Resolution
• 0.01C / 0.01% RH

• Response Time
• 5s (for humidity), 2s (for temperature)

• Sensitivity
• High sensitivity, precise environmental monitoring

• Sensor Type
• Digital/Capacitive Humidity & Semiconductor Temperature Sensor

• Signal Type
• Other, Analog and Digital Signals

• Spectral Range
• N/A (Not applicable for this sensor type)

• Usage
• Environmental Monitoring, HVAC, Industrial Automation

• Voltage
• 12V/24V DC or 230V AC (depending on model)

• Weight
• Variable (approx. 200-400g based on model)

• Wireless
• Other, Optional (on select models, e.g., WiFi/LoRa)

• Accuracy
• 0.5 % %

• Application
• Level measurement in tanks, silos, containers, water treatment plants, and other industrial process industries

• Connectivity Type
• Relay, RS485, Analog Output

• Current
• 4-20mA

• Diameter
• M75 2.0

• Display
• LED or LCD digital display

• Features
• Non-contact measurement, High accuracy, Easy installation and maintenance

• Frequency
• 20 KHz - 100 KHz

• IP Rating
• IP65

• Input
• 220V AC

• Installation Type
• Thread mounting

• Measuring Range
• 0-5m, 0-10m, 0-15m, 0-20m

• Mounting Type
• Threaded

• Operating Temperature
• -20C ~ 60C

• Output
• 4-20mA, relay output, RS485

• Phase
• Single Phase

• Pressure Type
• Atmospheric

• Product Type
• Ultrasonic Level Meter

• Protection Level
• IP65

• Sensor Type
• Ultrasonic

• Supply Voltage
• 220V AC or 24V DC

• Switch Type
• Relay Output

• Usage & Applications
• Liquid and solid level measurement

• Working Temperature
• -20C ~ 60C

• Accuracy
• 0.25% F.S.

• Application
• Water, wastewater, chemical, process tanks, industrial applications

• Cable Length
• 5m (standard), customizable

• Features
• LCD display, Easy Calibration, Maintenance Free, Corrosion Resistant, Compact Design

• Function
• Non-contact Level Measurement

• Housing Material
• Polypropylene (PP)

• IP Rating
• IP68

• Ingress Protection
• IP68

• Input
• 10-30V DC

• Interface
• RS485 / 4-20mA

• Material
• Engineering Plastic Body

• Measurement Range
• 0-5m, 0-10m, 0-15m, 0-20m (Model: AULM-20)

• Mounting Thread
• 2 inch BSP

• Mounting Type
• Threaded

• Operating Temperature
• -20C to +70C

• Output
• 4-20 mA/RS485

• Power Consumption
• 1.5 W

• Product Type
• Ultrasonic Level Transmitter

• Resolution
• 1 mm

• Response Time
• < 500 ms

• Sensitivity
• High

• Sensor Type
• Ultrasonic Sensor

• Signal Type
• Other, Analog / Digital

• Spectral Range
• Ultrasonic

• Usage
• Liquid, Slurry, and Solid Level Measurement

• Voltage
• 10-30V DC

• Weight
• 500 gm (approx.)

• Wireless
• No
