Product Description
Temperature Gauges
- Entry : Back / Bottom /EVERY ANGLE Type
- Dial : 100 Mm , 150 Mm
- Range : -25 To 600 Degree
- Stem Rod Length : 300mm
- Dia Of Rod : 6 Mm , 8 Mm , 10 Mm
- Accuracy : Up To Class 1 As Per En 13190
- connection : Bsp Male , Bsp Female
- Capillary : Length As Per Customer Required.
- Window : Safety Glass
Precision in MeasurementThese analog gauges feature scale graduations of 1C or 2C, depending on the dial size, ensuring clear and precise readings. The mechanical measurement using a bimetallic coil delivers a response time of approximately 40 seconds and an accuracy of 1.5% of full scale. Such calibration is ideal for environments where precise temperature tracking is vital.
Flexible Installation OptionsMounting options include panel, surface, and direct stem mounts, catering to diverse installation requirements. With stem lengths varying from 50 mm to 250 mm, and custom sizes available upon request, users can select the configuration that best suits their operational environment.
Built for DurabilityThe gauge features a stainless steel enclosure and is protected by a clear acrylic or glass window, providing robustness and resistance to harsh conditions. Select models are rated IP65, safeguarding against dust and low-pressure water jets, suitable for industrial and process monitoring applications.
FAQs of Temperature Gauges:
Q: How does the Analog Dial Temperature Gauge function mechanically?
A: The gauge operates using a bimetallic coil. As the temperature changes, the coil expands or contracts, causing the anodized aluminum pointer to move across the dial, indicating the measured temperature.
Q: What are the available connection and mounting options for these gauges?
A: Connection types include both bottom and back connections with 1/2" BSP or NPT threads. Mounting options are versatile, featuring panel, surface, and direct stem mounts to suit varying installation needs.
Q: When should an IP65-rated model be selected?
A: IP65-rated models are recommended when the gauge will be exposed to dusty environments or jets of water, commonly found in industrial and outdoor process monitoring applications, to ensure durability and continuous operation.
Q: Where can these temperature gauges be applied?
A: Analog Dial Temperature Gauges are suitable for industrial settings, HVAC systems, laboratory equipment, and any process monitoring scenario that requires manual temperature indication without electronic control.
Q: What are the benefits of choosing a gauge with clear acrylic or glass windows?
A: Clear acrylic or glass windows enhance visibility and safeguard the dial from environmental hazards, ensuring easy reading and prolonged device longevity.
Q: What temperature ranges and dial sizes are available?
A: These gauges cover a wide temperature range, from -40C to 600C, with standard dial sizes of 63mm, 100mm, and 150mm. The external case size varies accordingly, typically with a diameter of 150mm and depth of 35mm.
