Product Description
Differential Pressure Gauge Transmitter
Applications :
Low Cost Differential Pressure Gauge Is The Industry Standard To Measure Fan And Blower Pressures, Filter Resistance, Air Velocity, Furnace Draft, Pressure Drop Across Orifice Plates, Filter Status, Room Pressure, Duct Static Pressure, Paint Booths, Dust Collectors And Cabinet Purging Along With Many Others.
Versatile Applications Across IndustriesThis transmitter serves a wide array of settings, including clean rooms, HVAC systems, pharmaceutical laboratories, hospitals, and filter monitoring. Its adaptability makes it a valuable tool for controlling air quality and ensuring process integrity in sensitive environments. Customizable pressure range and external sizes further broaden its usability.
User-Friendly and Robust DesignCrafted with an aluminum alloy exterior and options for ABS or stainless steel internals, this device offers durability and precision. It features an LCD digital display for clear readings, manual zero and span adjustments for straightforward calibration, and IP54 protection for reliable performance in moderate environmental conditions. Its lightweight design facilitates hassle-free installation.
FAQs of Differential Pressure Gauge Transmitter:
Q: How does the differential pressure gauge transmitter operate in monitoring air and non-corrosive gases?
A: The transmitter senses pressure differences in air or non-corrosive gases and converts this data into an electrical signal (4-20mA, 0-10V, or RS485 MODBUS optional). It provides real-time readings on the LCD digital display, enabling continuous monitoring for critical applications such as clean rooms and HVAC systems.
Q: What are the output signal options, and when should I choose each type?
A: The transmitter offers 4-20mA, 0-10V, and RS485 MODBUS output signals. 4-20mA is widely used for long-distance analog signal transmission, 0-10V works well in shorter wiring setups, and RS485 MODBUS provides digital communication for integration with building automation systems. Selection depends on your existing system requirements and integration needs.
Q: Where can this differential pressure transmitter be installed?
A: Designed for flexibility, the transmitter can be wall-mounted or panel-mounted. Its compact and lightweight build, along with barbed fittings for 6mm hose, allows for convenient placement in clean rooms, laboratories, monitoring panels, or HVAC equipment setups.
Q: What steps are involved in calibrating the device using the manual zero and span adjustment buttons?
A: Calibration can be performed via the manual buttons on the front panel. Press the zero button to set the baseline (zero point) and use the span button to adjust the measurement range to match the desired scale, ensuring accurate readings when switching applications or performing routine maintenance.
Q: How does the IP54 ingress protection benefit the device in practical applications?
A: IP54 rating means the transmitter is safeguarded against moderate dust ingress and splashing water, making it well-suited for laboratory and industrial environments where such conditions occur. This enhances reliability and minimizes the risk of malfunction due to environmental factors.
Q: What makes this differential pressure transmitter suitable for clean rooms and pharmaceutical industries?
A: Its high accuracy (1% F.S.), fast response time (1s), and reliable LCD display ensure precise control of room pressure, vital for maintaining contamination-free areas. It supports strict air quality standards required by clean rooms, pharmaceuticals, and medical facilities.
